PureSmart glovebox workstation: Your Go To Solution for Inert Research Applications.

The PureSmart glovebox system is designed to offer an economical setup for research laboratories and special operation under pure atmosphere. Experience unparalleled user-friendly operation for your research environment with the PureSmart System, engineered to maintain oxygen and moisture levels below 1ppm.

The standard configuration embeds a single column gas purifier (regenerable Core 8), a last generation 7” color touch screen, a 21m3/h (top of the class capacity) rotary vane pump with oil mist eliminator & oil return kit (only used for the antechambers’ vacuum conditioning cycles), a large antechamber (Ø400 x 600mm), an electrical feedthrough and 6 blank feedthroughs. PureSmart gloveboxes and easily connect with extension boxes or PureMod model, providing modularity and flexibility to your system.

A Fully Equipped Glove Box

The PURESMART is a standard and fully equipped glove box with an autonomous purification unit, an automatic pressure regulation without vacuum pump, a transfer airlock with a 21m3/h double-stage vacuum pump, a purification unit with automatic regeneration and H2O and/or O2 analyzers.

It is also fitted with a high-definition, easy-to-read 7” touch screen. The newly developed HMI interface allows intuitive and easy-to-use navigation. Adjustable parameters and continuous recording with plotted data (H20, O2, Pr, T) allow you to work efficiently in complete safety. The PLC interface integrates support and maintenance management for optimal trouble-free operation.

PureSmart Glovebox Workstation Overview

Eco-Energy mode (Energy Saving Mode 24/24)

Naturally, the model comes equipped with our original Eco-Energy mode (Energy Saving Mode 24/24) as standard: In a process of reducing energy needs, respecting the planet and committing against obsolescence, Jacomex was the original designer of the Economic Operating Mode 15 years ago. This mode has been developed in order to increase the lifespan of the components and to prolong their reliability over time. Unlike some models on the market, our Energy Saving Mode 24/24 is continuously operational, not only in standby mode (excluding manipulations) but also in use (during manipulations).

ADVANTAGES

pre-equipped modules for plug-and-play extension

Short purification circuit - Enhanced performance

High purification capacities designed to purify no less than 2 to 3 modules
- Purification loads among the most quantitative on the market for equivalent range

Pressure regulation without vacuum pump (positive pressure/negative pressure)

Comfortable to use - Quiet

Short delivery time

Easy and accessible maintenance

Long service life - Low operating costs
